#include <cryptlib.h>
Inheritance diagram for BufferedTransformation:
BufferedTransformation is a generalization of BlockTransformation, StreamTransformation, and HashTransformation.
A buffered transformation is an object that takes a stream of bytes as input (this may be done in stages), does some computation on them, and then places the result into an internal buffer for later retrieval. Any partial result already in the output buffer is not modified by further input.
If a method takes a "blocking" parameter, and you pass "false" for it, the method will return before all input has been processed if the input cannot be processed without waiting (for network buffers to become available, for example). In this case the method will return true or a non-zero integer value. When this happens you must continue to call the method with the same parameters until it returns false or zero, before calling any other method on it or attached BufferedTransformation. The integer return value in this case is approximately the number of bytes left to be processed, and can be used to implement a progress bar.
For functions that take a "propagation" parameter, propagation != 0 means pass on the signal to attached BufferedTransformation objects, with propagation decremented at each step until it reaches 0. -1 means unlimited propagation.
Definition at line 711 of file cryptlib.h.
INPUT | |
| size_t | Put (byte inByte, bool blocking=true) |
| input a byte for processing | |
| size_t | Put (const byte *inString, size_t length, bool blocking=true) |
| input multiple bytes | |
| size_t | PutWord16 (word16 value, ByteOrder order=BIG_ENDIAN_ORDER, bool blocking=true) |
| input a 16-bit word | |
| size_t | PutWord32 (word32 value, ByteOrder order=BIG_ENDIAN_ORDER, bool blocking=true) |
| input a 32-bit word | |
| virtual byte * | CreatePutSpace (size_t &size) |
| request space which can be written into by the caller, and then used as input to Put() | |
| virtual bool | CanModifyInput () const |
| size_t | PutModifiable (byte *inString, size_t length, bool blocking=true) |
| input multiple bytes that may be modified by callee | |
| bool | MessageEnd (int propagation=-1, bool blocking=true) |
| size_t | PutMessageEnd (const byte *inString, size_t length, int propagation=-1, bool blocking=true) |
| virtual size_t | Put2 (const byte *inString, size_t length, int messageEnd, bool blocking)=0 |
| input multiple bytes for blocking or non-blocking processing | |
| virtual size_t | PutModifiable2 (byte *inString, size_t length, int messageEnd, bool blocking) |
| input multiple bytes that may be modified by callee for blocking or non-blocking processing | |
WAITING | |
| unsigned int | GetMaxWaitObjectCount () const |
| maximum number of wait objects that this object can return | |
| void | GetWaitObjects (WaitObjectContainer &container, CallStack const &callStack) |
| put wait objects into container | |
SIGNALS | |
| virtual void | IsolatedInitialize (const NameValuePairs ¶meters) |
| virtual bool | IsolatedFlush (bool hardFlush, bool blocking)=0 |
| virtual bool | IsolatedMessageSeriesEnd (bool blocking) |
| virtual void | Initialize (const NameValuePairs ¶meters=g_nullNameValuePairs, int propagation=-1) |
| initialize or reinitialize this object | |
| virtual bool | Flush (bool hardFlush, int propagation=-1, bool blocking=true) |
| flush buffered input and/or output | |
| virtual bool | MessageSeriesEnd (int propagation=-1, bool blocking=true) |
| mark end of a series of messages | |
| virtual void | SetAutoSignalPropagation (int propagation) |
| set propagation of automatically generated and transferred signals | |
| virtual int | GetAutoSignalPropagation () const |
RETRIEVAL OF ONE MESSAGE | |
| virtual lword | MaxRetrievable () const |
| returns number of bytes that is currently ready for retrieval | |
| virtual bool | AnyRetrievable () const |
| returns whether any bytes are currently ready for retrieval | |
| virtual size_t | Get (byte &outByte) |
| try to retrieve a single byte | |
| virtual size_t | Get (byte *outString, size_t getMax) |
| try to retrieve multiple bytes | |
| virtual size_t | Peek (byte &outByte) const |
| peek at the next byte without removing it from the output buffer | |
| virtual size_t | Peek (byte *outString, size_t peekMax) const |
| peek at multiple bytes without removing them from the output buffer | |
| size_t | GetWord16 (word16 &value, ByteOrder order=BIG_ENDIAN_ORDER) |
| try to retrieve a 16-bit word | |
| size_t | GetWord32 (word32 &value, ByteOrder order=BIG_ENDIAN_ORDER) |
| try to retrieve a 32-bit word | |
| size_t | PeekWord16 (word16 &value, ByteOrder order=BIG_ENDIAN_ORDER) const |
| try to peek at a 16-bit word | |
| size_t | PeekWord32 (word32 &value, ByteOrder order=BIG_ENDIAN_ORDER) const |
| try to peek at a 32-bit word | |
| lword | TransferTo (BufferedTransformation &target, lword transferMax=LWORD_MAX, const std::string &channel=NULL_CHANNEL) |
| move transferMax bytes of the buffered output to target as input | |
| virtual lword | Skip (lword skipMax=LWORD_MAX) |
| discard skipMax bytes from the output buffer | |
| lword | CopyTo (BufferedTransformation &target, lword copyMax=LWORD_MAX, const std::string &channel=NULL_CHANNEL) const |
| copy copyMax bytes of the buffered output to target as input | |
| lword | CopyRangeTo (BufferedTransformation &target, lword position, lword copyMax=LWORD_MAX, const std::string &channel=NULL_CHANNEL) const |
| copy copyMax bytes of the buffered output, starting at position (relative to current position), to target as input | |
RETRIEVAL OF MULTIPLE MESSAGES | |
| virtual lword | TotalBytesRetrievable () const |
| virtual unsigned int | NumberOfMessages () const |
| number of times MessageEnd() has been received minus messages retrieved or skipped | |
| virtual bool | AnyMessages () const |
| returns true if NumberOfMessages() > 0 | |
| virtual bool | GetNextMessage () |
| start retrieving the next message | |
| virtual unsigned int | SkipMessages (unsigned int count=UINT_MAX) |
| skip count number of messages | |
| unsigned int | TransferMessagesTo (BufferedTransformation &target, unsigned int count=UINT_MAX, const std::string &channel=NULL_CHANNEL) |
| unsigned int | CopyMessagesTo (BufferedTransformation &target, unsigned int count=UINT_MAX, const std::string &channel=NULL_CHANNEL) const |
| virtual void | SkipAll () |
| void | TransferAllTo (BufferedTransformation &target, const std::string &channel=NULL_CHANNEL) |
| void | CopyAllTo (BufferedTransformation &target, const std::string &channel=NULL_CHANNEL) const |
| virtual bool | GetNextMessageSeries () |
| virtual unsigned int | NumberOfMessagesInThisSeries () const |
| virtual unsigned int | NumberOfMessageSeries () const |
NON-BLOCKING TRANSFER OF OUTPUT | |
| virtual size_t | TransferTo2 (BufferedTransformation &target, lword &byteCount, const std::string &channel=NULL_CHANNEL, bool blocking=true)=0 |
| upon return, byteCount contains number of bytes that have finished being transfered, and returns the number of bytes left in the current transfer block | |
| virtual size_t | CopyRangeTo2 (BufferedTransformation &target, lword &begin, lword end=LWORD_MAX, const std::string &channel=NULL_CHANNEL, bool blocking=true) const =0 |
| upon return, begin contains the start position of data yet to be finished copying, and returns the number of bytes left in the current transfer block | |
| size_t | TransferMessagesTo2 (BufferedTransformation &target, unsigned int &messageCount, const std::string &channel=NULL_CHANNEL, bool blocking=true) |
| upon return, messageCount contains number of messages that have finished being transfered, and returns the number of bytes left in the current transfer block | |
| size_t | TransferAllTo2 (BufferedTransformation &target, const std::string &channel=NULL_CHANNEL, bool blocking=true) |
| returns the number of bytes left in the current transfer block | |
CHANNELS | |
| size_t | ChannelPut (const std::string &channel, byte inByte, bool blocking=true) |
| size_t | ChannelPut (const std::string &channel, const byte *inString, size_t length, bool blocking=true) |
| size_t | ChannelPutModifiable (const std::string &channel, byte *inString, size_t length, bool blocking=true) |
| size_t | ChannelPutWord16 (const std::string &channel, word16 value, ByteOrder order=BIG_ENDIAN_ORDER, bool blocking=true) |
| size_t | ChannelPutWord32 (const std::string &channel, word32 value, ByteOrder order=BIG_ENDIAN_ORDER, bool blocking=true) |
| bool | ChannelMessageEnd (const std::string &channel, int propagation=-1, bool blocking=true) |
| size_t | ChannelPutMessageEnd (const std::string &channel, const byte *inString, size_t length, int propagation=-1, bool blocking=true) |
| virtual byte * | ChannelCreatePutSpace (const std::string &channel, size_t &size) |
| virtual size_t | ChannelPut2 (const std::string &channel, const byte *begin, size_t length, int messageEnd, bool blocking) |
| virtual size_t | ChannelPutModifiable2 (const std::string &channel, byte *begin, size_t length, int messageEnd, bool blocking) |
| virtual bool | ChannelFlush (const std::string &channel, bool hardFlush, int propagation=-1, bool blocking=true) |
| virtual bool | ChannelMessageSeriesEnd (const std::string &channel, int propagation=-1, bool blocking=true) |
| virtual void | SetRetrievalChannel (const std::string &channel) |
ATTACHMENT | |
| virtual bool | Attachable () |
| returns whether this object allows attachment | |
| virtual BufferedTransformation * | AttachedTransformation () |
| returns the object immediately attached to this object or NULL for no attachment | |
| virtual const BufferedTransformation * | AttachedTransformation () const |
| virtual void | Detach (BufferedTransformation *newAttachment=0) |
| delete the current attachment chain and replace it with newAttachment | |
| virtual void | Attach (BufferedTransformation *newAttachment) |
| add newAttachment to the end of attachment chain | |
Public Member Functions | |
| BufferedTransformation () | |
| BufferedTransformation & | Ref () |
| return a reference to this object | |
| virtual std::string | AlgorithmName () const |
| returns name of this algorithm, not universally implemented yet | |
| virtual Clonable * | Clone () const |
| this is not implemented by most classes yet | |
| bool | Wait (unsigned long milliseconds, CallStack const &callStack) |
| wait on this object | |
Static Public Attributes | |
| static const std::string | NULL_CHANNEL |
Static Protected Member Functions | |
| static int | DecrementPropagation (int propagation) |
Classes | |
| struct | BlockingInputOnly |
| thrown by objects that have not implemented nonblocking input processing More... | |
| struct | NoChannelSupport |
| BufferedTransformation& BufferedTransformation::Ref | ( | ) | [inline] |
return a reference to this object
This function is useful for passing a temporary BufferedTransformation object to a function that takes a non-const reference.
Definition at line 722 of file cryptlib.h.
| virtual byte* BufferedTransformation::CreatePutSpace | ( | size_t & | size | ) | [inline, virtual] |
request space which can be written into by the caller, and then used as input to Put()
Reimplemented in MeterFilter, HashFilter, Redirector, OutputProxy, ArraySink, ArrayXorSink, ByteQueue, Multichannel< Filter >, and Multichannel< Sink >.
Definition at line 741 of file cryptlib.h.
Referenced by ChannelCreatePutSpace(), and ArrayXorSink::CreatePutSpace().
| virtual size_t BufferedTransformation::Put2 | ( | const byte * | inString, | |
| size_t | length, | |||
| int | messageEnd, | |||
| bool | blocking | |||
| ) | [pure virtual] |
input multiple bytes for blocking or non-blocking processing
| messageEnd | means how many filters to signal MessageEnd to, including this one |
Implemented in BaseN_Encoder, BaseN_Decoder, Grouper, PK_DefaultEncryptionFilter, PK_DefaultDecryptionFilter, FileSink, MeterFilter, FilterWithBufferedInput, FilterWithInputQueue, HashFilter, SignerFilter, Redirector, OutputProxy, StringSinkTemplate< T >, ArraySink, ArrayXorSink, SecretSharing, InformationDispersal, PaddingRemover, MessageQueue, NetworkSink, ByteQueue, RandomPool, MaurerRandomnessTest, BitBucket, FilterTester, Deflator, Inflator, InputRejecting< BufferedTransformation >, InputRejecting< Filter >, Multichannel< Filter >, and Multichannel< Sink >.
Referenced by ChannelPut2(), and Filter::Output().
| virtual size_t BufferedTransformation::PutModifiable2 | ( | byte * | inString, | |
| size_t | length, | |||
| int | messageEnd, | |||
| bool | blocking | |||
| ) | [inline, virtual] |
input multiple bytes that may be modified by callee for blocking or non-blocking processing
| messageEnd | means how many filters to signal MessageEnd to, including this one |
Reimplemented in MeterFilter, FilterWithBufferedInput, OutputProxy, Multichannel< Filter >, and Multichannel< Sink >.
Definition at line 759 of file cryptlib.h.
Referenced by ChannelPutModifiable2(), NetworkSource::DoPump(), and Filter::OutputModifiable().
| void BufferedTransformation::GetWaitObjects | ( | WaitObjectContainer & | container, | |
| CallStack const & | callStack | |||
| ) | [virtual] |
put wait objects into container
| callStack | is used for tracing no wait loops, example: something.GetWaitObjects(c, CallStack("my func after X", 0));
|
Implements Waitable.
Reimplemented in Redirector, NetworkSource, and NetworkSink.
Definition at line 188 of file cryptlib.cpp.
References AttachedTransformation(), and GetWaitObjects().
Referenced by NetworkSource::GetWaitObjects(), and GetWaitObjects().
| bool BufferedTransformation::Flush | ( | bool | hardFlush, | |
| int | propagation = -1, |
|||
| bool | blocking = true | |||
| ) | [virtual] |
flush buffered input and/or output
| hardFlush | is used to indicate whether all data should be flushed |
Reimplemented in Filter, Redirector, OutputProxy, SecretSharing, InformationDispersal, Unflushable< Filter >, Unflushable< Sink >, Unflushable< Multichannel< Filter > >, Multichannel< Filter >, and Multichannel< Sink >.
Definition at line 201 of file cryptlib.cpp.
References AttachedTransformation().
Referenced by ChannelFlush().
| bool BufferedTransformation::MessageSeriesEnd | ( | int | propagation = -1, |
|
| bool | blocking = true | |||
| ) | [virtual] |
mark end of a series of messages
There should be a MessageEnd immediately before MessageSeriesEnd.
Reimplemented in Filter, Redirector, OutputProxy, Multichannel< Filter >, and Multichannel< Sink >.
Definition at line 207 of file cryptlib.cpp.
References AttachedTransformation(), and IsolatedMessageSeriesEnd().
Referenced by EqualityComparisonFilter::ChannelMessageSeriesEnd(), ChannelMessageSeriesEnd(), and EncodedObjectFilter::Put().
| virtual void BufferedTransformation::SetAutoSignalPropagation | ( | int | propagation | ) | [inline, virtual] |
set propagation of automatically generated and transferred signals
propagation == 0 means do not automaticly generate signals
Reimplemented in SourceTemplate< T >, SourceTemplate< FileStore >, SourceTemplate< RandomNumberStore >, SourceTemplate< StringStore >, AutoSignaling< BufferedTransformation >, AutoSignaling< InputRejecting< BufferedTransformation > >, AutoSignaling< Filter >, AutoSignaling< Source >, and AutoSignaling< Unflushable< Multichannel< Filter > > >.
Definition at line 799 of file cryptlib.h.
| lword BufferedTransformation::MaxRetrievable | ( | ) | const [virtual] |
returns number of bytes that is currently ready for retrieval
All retrieval functions return the actual number of bytes retrieved, which is the lesser of the request number and MaxRetrievable().
Reimplemented in FileStore, RandomNumberStore, NullStore, MessageQueue, ByteQueue, ByteQueue::Walker, and RandomPool.
Definition at line 253 of file cryptlib.cpp.
References AttachedTransformation(), CopyTo(), and MaxRetrievable().
Referenced by RandomNumberStore::AnyRetrievable(), Integer::BERDecode(), Integer::Decode(), DL_GroupParameters_EC< EC >::Initialize(), MaxRetrievable(), EcRecommendedParameters< ECP >::NewEC(), EcRecommendedParameters< EC2N >::NewEC(), Integer::OpenPGPDecode(), and TotalBytesRetrievable().
| bool BufferedTransformation::GetNextMessage | ( | ) | [virtual] |
start retrieving the next message
Returns false if no more messages exist or this message is not completely retrieved.
Reimplemented in MessageQueue, and Store.
Definition at line 342 of file cryptlib.cpp.
References AnyMessages(), AttachedTransformation(), and GetNextMessage().
Referenced by GetNextMessage(), and TransferMessagesTo2().
| virtual bool BufferedTransformation::Attachable | ( | ) | [inline, virtual] |
returns whether this object allows attachment
Some BufferedTransformation objects (e.g. Filter objects) allow other BufferedTransformation objects to be attached. When this is done, the first object instead of buffering its output, sents that output to the attached object as input. The entire attachment chain is deleted when the anchor object is destructed.
Reimplemented in Filter.
Definition at line 949 of file cryptlib.h.
Referenced by Attach().
| bool Waitable::Wait | ( | unsigned long | milliseconds, | |
| CallStack const & | callStack | |||
| ) | [inherited] |
wait on this object
same as creating an empty container, calling GetWaitObjects(), and calling Wait() on the container
Definition at line 388 of file wait.cpp.
References Waitable::GetWaitObjects(), and WaitObjectContainer::Wait().
Referenced by NetworkSink::DoFlush(), and NetworkSource::DoPump().
1.5.1-p1
